ULTRA LOW PROFILE AND HIGH POWER ! PROGRAMMABLE DC POWER SUPPLY

  • Output voltage: 10V to 650V
  • Output current: 1.2A to 1200A
  • Output power: 0.75kW to 15kW
  • Wide selection of models
UL marking (For some models)

OUR ORIGINAL SWITCHING TECHNOLOGY HAS REALIZED HIGH POWER,
COMPACT AND HIGH EFFICIENT PROGRAMMABLE DC POWER SUPPLY RE SERIES.

Minimum heat release coupled with its compactness of 1/10 the size and 1/20 the weight of conventional power supply have enabled high-density mounting.
RE's low power consumption contributes to low running cost and environmental issues.
Various remote control and monitor functions are standard and digital interface is available as option, which enable RE to support various systems.
The best model can be chosen for your application from wide lineup of 140 models, from 10 V to 650 V, and 0.75 kW to 15 kW.
Upgrading of up to 60 kW is possible with master/slave option. (Some models correspond to UL)

FEATURES AND BENEFITS

  • Analog control/High power DC power supplies
  • Digital control available via various interfaces
  • Wide selection of models

Models

Model Maximum Output Ripple *1 Ripple *2 Safety standards
Voltage [V] Current [A] Power [kW] [mVrms] [mArms]
RE10-75 10 V 75 A 0.75 kW 10 mVrms 150 mArms UL recognized component marks for canada and the united states
RE10-110 110 A 1.1 kW 10 mVrms 220 mArms UL recognized component marks for canada and the united states
RE10-200 200 A 2 kW 10 mVrms 400 mArms
RE10-300 300 A 3 kW 15 mVrms 600 mArms
RE10-400 400 A 4 kW 15 mVrms 800 mArms
RE10-450 450 A 4.5 kW 30 mVrms 900 mArms
RE10-750 750 A 7.5 kW 20 mVrms 2400 mArms
RE10-820 820 A 8.2 kW 30 mVrms 3600 mArms
RE10-1000 1000 A 10 kW 30 mVrms 4800 mArms
RE10-1200 1200 A 12 kW 30 mVrms 4800 mArms
RE15-50 15 V 50 A 0.75 kW 10 mVrms 100 mArms UL recognized component marks for canada and the united states
RE15-80 80 A 1.2 kW 10 mVrms 160 mArms UL recognized component marks for canada and the united states
RE15-120 120 A 1.8 kW 10 mVrms 250 mArms
RE15-200 200 A 3 kW 10 mVrms 400 mArms
RE15-250 250 A 3.75 kW 15 mVrms 500 mArms
RE15-300 300 A 4.5 kW 15 mVrms 600 mArms
RE15-500 500 A 7.5 kW 30 mVrms 2500 mArms
RE15-560 560 A 8.4 kW 30 mVrms 2500 mArms
RE15-700 700 A 10.5 kW 35 mVrms 3500 mArms
RE20-38 20 V 38 A 0.76 kW 10 mVrms 80 mArms UL recognized component marks for canada and the united states
RE20-60 60 A 1.2 kW 10 mVrms 120 mArms UL recognized component marks for canada and the united states
RE20-100 100 A 2 kW 10 mVrms 200 mArms
RE20-150 150 A 3 kW 15 mVrms 300 mArms
RE20-200 200 A 4 kW 10 mVrms 400 mArms
RE20-250 250 A 5 kW 15 mVrms 500 mArms
RE20-375 375 A 7.5 kW 30 mVrms 1200 mArms
RE20-400 400 A 8 kW 20 mVrms 2400 mArms
RE20-430 430 A 8.6 kW 35 mVrms 2400 mArms
RE20-500 500 A 10 kW 35 mVrms 2400 mArms
RE20-600 600 A 12 kW 30 mVrms 2400 mArms
RE30-25 30 V 25 A 0.75 kW 10 mVrms 50 mArms UL recognized component marks for canada and the united states
RE30-40 40 A 1.2 kW 15 mVrms 80 mArms UL recognized component marks for canada and the united states
RE30-65 65 A 1.95 kW 20 mVrms 130 mArms
RE30-100 100 A 3 kW 20 mVrms 200 mArms
RE30-130 130 A 3.9 kW 30 mVrms 260 mArms
RE30-170 170 A 5.1 kW 30 mVrms 340 mArms
RE30-250 250 A 7.5 kW 20 mVrms 500 mArms
RE30-290 290 A 8.7 kW 30 mVrms 700 mArms
RE30-350 350 A 10.5 kW 30 mVrms 800 mArms
RE30-400 400 A 12 kW 20 mVrms 800 mArms
RE35-22 35 V 22 A 0.77 kW 10 mVrms 50 mArms UL recognized component marks for canada and the united states
RE35-34 34 A 1.2 kW 10 mVrms 70 mArms UL recognized component marks for canada and the united states
RE35-60 60 A 2.1 kW 20 mVrms 120 mArms
RE35-85 85 A 3 kW 20 mVrms 170 mArms
RE35-115 115 A 4 kW 20 mVrms 230 mArms
RE35-140 140 A 4.9 kW 30 mVrms 280 mArms
RE35-215 215 A 7.5 kW 35 mVrms 1800 mArms
RE35-240 240 A 8.4 kW 35 mVrms 2000 mArms
RE35-300 300 A 10.5 kW 35 mVrms 2000 mArms
RE35-340 340 A 11.9 kW 35 mVrms 2400 mArms
RE40-100 40 100 A 4 kW 30 mVrms 300 mArms
RE40-220 220 A 8.8 kW 30 mVrms 350 mArms
RE45-17 45 V 17 A 0.765 kW 18 mVrms 40 mArms UL recognized component marks for canada and the united states
RE45-27 27 A 1.2 kW 18 mVrms 60 mArms UL recognized component marks for canada and the united states
RE45-45 45 A 2 kW 30 mVrms 90 mArms
RE45-66 66 A 3 kW 30 mVrms 130 mArms
RE45-90 90 A 4 kW 30 mVrms 180 mArms
RE45-110 110 A 5 kW 45 mVrms 220 mArms
RE45-165 165 A 7.5 kW 45 mVrms 750 mArms
RE45-220 220 A 9.9 kW 45 mVrms 1100 mArms
RE45-260 260 A 11.7 kW 45 mVrms 1300 mArms
RE60-12.5 60 V 12.5 A 0.75 kW 20 mVrms 25 mArms UL recognized component marks for canada and the united states
RE60-20 20 A 1.2 kW 20 mVrms 40 mArms UL recognized component marks for canada and the united states
RE60-35 35 A 2.1 kW 15 mVrms 70 mArms
RE60-50 50 A 3 kW 20 mVrms 100 mArms
RE60-67 67 A 4 kW 20 mVrms 135 mArms
RE60-83 83 A 5 kW 30 mVrms 170 mArms
RE60-125 125 A 7.5 kW 30 mVrms 350 mArms
RE60-140 140 A 8.4 kW 30 mVrms 350 mArms
RE60-170 170 A 10.2 kW 35 mVrms 500 mArms
RE60-200 200 A 12 kW 35 mVrms 500 mArms
RE60-220 220 A 13.2 kW 35 mVrms 500 mArms
RE60-250 250 A 15 kW 25 mVrms 500 mArms
RE80-110 80 V 110 A 8.8 kW 80 mVrms 600 mArms
RE100-7.5 100 V 7.5 A 0.75 kW 20 mVrms 15 mArms
RE100-12 12 A 1.2 kW 20 mVrms 25 mArms
RE100-20 20 A 2 kW 20 mVrms 40 mArms
RE100-30 30 A 3 kW 30 mVrms 60 mArms
RE100-40 40 A 4 kW 30 mVrms 80 mArms
RE100-50 50 A 5 kW 40 mVrms 100 mArms
RE100-75 75 A 7.5 kW 60 mVrms 300 mArms
RE100-84 84 A 8.4 kW 60 mVrms 350 mArms
RE100-100 100 A 10 kW 100 mVrms 800 mArms
RE100-150 150 A 15 kW 100 mVrms 1000 mArms
RE150-5 150 V 5 A 0.75 kW 30 mVrms 10 mArms
RE150-8 8 A 1.2 kW 30 mVrms 20 mArms
RE150-14 14 A 2.1 kW 25 mVrms 30 mArms
RE150-20 20 A 3 kW 30 mVrms 40 mArms
RE150-27 27 A 4 kW 30 mVrms 55 mArms
RE150-33 33 A 5 kW 60 mVrms 70 mArms
RE150-50 50 A 7.5 kW 70 mVrms 100 mArms
RE150-56 56 A 8.4 kW 70 mVrms 100 mArms
RE150-70 70 A 10.5 kW 150 mVrms 200 mArms
RE150-100 100 A 15 kW 100 mVrms 200 mArms
RE160-27 160 V 27 A 4.3 30 mVrms 55 mArms
RE160-55 55 A 8.8 kW 160 mVrms 200 mArms
RE200-3.8 200 V 3.8 A 0.76 kW 40 mVrms 10 mArms
RE200-6 6 A 1.2 kW 40 mVrms 15 mArms UL recognized component marks for canada and the united states
RE200-10 10 A 2 kW 40 mVrms 20 mArms
RE200-15 15 A 3 kW 40 mVrms 30 mArms UL recognized component marks for canada and the united states
RE200-20 20 A 4 kW 200 mVrms 40 mArms
RE200-25 25 A 5 kW 200 mVrms 50 mArms
RE200-37 37 A 7.4 kW 200 mVrms 280 mArms
RE200-42 42 A 8.4 kW 150 mVrms 200 mArms
RE200-50 50 A 10 kW 200 mVrms 380 mArms
RE200-75 75 A 15 kW 200 mVrms 530 mArms
RE250-35 250 V 35 A 8.7 kW 100 mVrms 150 mArms
RE300-2.5 300 V 2.5 A 0.75 kW 50 mVrms 5 mArms
RE300-4 4 A 1.2 kW 50 mVrms 10 mArms
RE300-6.5 6.5 A 2 kW 50 mVrms 15 mArms
RE300-10 10 A 3 kW 50 mVrms 20 mArms
RE300-13 13 A 3.9 kW 300 mVrms 30 mArms
RE300-16 16 A 4.8 kW 300 mVrms 35 mArms
RE300-25 25 A 7.5 kW 100 mVrms 50 mArms
RE300-28 28 A 8.4 kW 100 mVrms 50 mArms
RE300-35 35 A 10.5 kW 300 mVrms 100 mArms
RE300-50 50 A 15 kW 150 mVrms 100 mArms
RE350-21 350 V 21 A 7.35 kW 150 mVrms 100 mArms
RE350-24 24 A 8.4 kW 150 mVrms 100 mArms
RE350-28 28 A 9.8 kW 150 mVrms 100 mArms
RE350-42 42 A 14.7 kW 150 mVrms 100 mArms
RE400-18.7 400 V 18.7 A 7.5 kW 200 mVrms 100 mArms
RE400-37.5 37.5 A 15 kW 200 mVrms 100 mArms
RE450-16.7 450 V 16.7 A 7.5 kW 200 mVrms 50 mArms
RE450-33.3 33.3 A 15 kW 200 mVrms 100 mArms
RE500-1.5 500 V 1.5 A 0.75 kW 150 mVrms 5 mArms
RE500-2.4 2.4 A 1.2 kW 150 mVrms 5 mArms
RE500-4 4 A 2 kW 150 mVrms 10 mArms
RE500-6 6 A 3 kW 150 mVrms 15 mArms
RE500-8 8 A 4 kW 500 mVrms 20 mArms
RE500-10 10 A 5 kW 500 mVrms 20 mArms
RE500-15 15 A 7.5 kW 200 mVrms 50 mArms
RE500-17 17 A 8.5 kW 200 mVrms 50 mArms
RE500-20 20 A 10 kW 500 mVrms 100 mArms
RE500-30 30 A 15 kW 200 mVrms 100 mArms
RE600-12.5 600 V 12.5 A 7.5 kW 100 mVrms 25 mArms
RE600-25 25 A 15 kW 100 mVrms 50 mArms
RE650-1.2 650 V 1.2 A 0.78 kW 200 mVrms 5 mArms
RE650-1.8 1.8 A 1.2 kW 200 mVrms 5 mArms
RE650-3 3 A 2 kW 200 mVrms 10 mArms
RE650-4.5 4.5 A 2.9 kW 200 mVrms 10 mArms
RE650-6 6 A 3.9 kW 200 mVrms 15 mArms
RE650-7.7 7.7 A 5 kW 200 mVrms 20 mArms
RE650-11 11 A 7.2 kW 200 mVrms 50 mArms
RE650-13.5 13.5 A 8.8 kW 250 mVrms 50 mArms
RE650-16 16 A 10.4 kW 250 mVrms 50 mArms
RE650-23 23 A 15 kW 300 mVrms 100 mArms

UL recognized component marks for canada and the united states: As for UL listed models, “-UL” is added to the end of the model name. <Example> RE35-22-UL
There is no option to the UL listed model.

  1. Rated output voltage when output current is 10% to 100% of rating.
  2. Rated output current when output voltage is 10% to 100% of rating.

Functions

Remote control connector (TB1)

* Please use TB1 in floating as TB1 and minus output is connected in the internal part.
  • REMOTE/LOCAL change
    As for the output voltage control, output current control, and overvoltage protection, the remote/local mode can be individually switched by relay or TTL signal.
  • External output ON/OFF
    Output can be turned ON/OFF by relay or TTL signal.
    Logic of signal can be selected by entering 5 V.
  • Output voltage control
  • Output current control
  • Overvoltage protection
  • Output monitor (Voltage, Current)
  • Output of status
    Common is floating with the output of open collector for each COMMON.

Function setting switch (SW1)

  • Output voltage control
    0 to 10 V Local ⇔ 0 to 10 kΩ approx.
  • Output current control
    0 to 10 V Local ⇔ 0 to 10 kΩ approx.
  • Overtemperature protection
    Manual reset ⇔ Auto reset
  • Power failure protection
    ON ⇔ OFF (ON/OFF by AC)

Remote sensing

Prevents voltage drop down (Vo-VL) due resistance (R) or deterioration of stability by contact resistance (Max 0.5 V)

Remote sensing

Output terminal

The form differs depending on the MODEL. Please check which form in dimension.

Output terminal

* To an output terminal cover for terminal board models, two places of holes of 8 mm in diameter are arranged as standard specifications.
A diameter bigger than 8 mm is also available.
Please contact our sales office for details.

Specifications

Input Voltage/Current
MODEL
(Output power)		 Input voltage
(±10% AC50/60 Hz)		 Phase Input current Input current protection
When PFC
(Typ.) *1		 Normal
(Typ.) *1		 Rush
(p-p)
0.75 kW to 0.78 kW 115V 1 - 12 A 60 A Fuse 30 A
230 V 8 A
1.1 kW to 1.2 kW 115 V 1 - 19 A 90 A
230 V 11 A
1.8 kW to 2.1 kW 220V 1 - 17A 100 A
3 10 A
2.9 kW to 3 kW 220 V 3 - 14 A 100 A
3.75 kW to 4 kW 220 V 3 15 A 19 A 100 A Circuit protector 30 A
4.3 kW to 5.1 kW 220 V 3 16 A 23 A
7.2 kW to 7.5 kW 10 V, 15 V 220 V 3 25 A *2 35 A 100 A Circuit protector 60 A
20 V to 60 V 34 A
over 100 V 33 A
8 kW to 10.5 kW 10V, 15V 220 V 3 36 A 46 A 100 A
20 V to 60 V 34 A 44 A
80 V to 100 V 32 A *3 41 A
11.7 kW to 12 kW 220 V 3 40 A *3 54 A 150 A Circuit protector 100 A *2
13.2 kW to 15 kW 220 V 3 50 A 68 A
  1. At rated input voltage
  2. Circuit protector 30 A
  3. Circuit protector 60 A

For more specification details, download the datasheet below.

Options

-LCP *2

Constant power control
(Voltage control is eliminated. Limited at maximum rated voltage)

-LEt *2

LAN interface board

-LGb *1

GPIB interface board

-LGob *1 *2

Optical Interface board

With optical communication, isolation control is performed. As complete isolation is performed by means of optical fiber, this enables advance prevention of erroneous operation involved with transient phenomenon caused by surges, inductive lightning, external noise, etc.

  • -LGob: Optical interface board + optical cable 2 meters
  • -LGob(Fc5): Optical interface board + optical cable 5 meters
  • -LGob(Fc10): Optical interface board + optical cable 10 meters
  • -LGob(Fc20): Optical interface board + optical cable 20 meters
  • -LGob(Fc40): Optical interface board + optical cable 40 meters

Select the optional optical interface board (-LGob) when using this DC power supply under the following conditions.

  • Noisy environment including factories (Example: Motors or coils are used near power supplies and loads).
  • Using with high voltage floating (more than 250 V)
  • Installation distance of 2 meters or more between the DC power supply and a controller such as a computer, laptop, or Programmable Logic Controller (PLC).

Adapters (sold separately)

An adapter is required separately, when using the Adapter.
The following adapters are available according to the connection method between PC and sequencer.

Adapter for LAN: CO-E32

Total 32 units can be connected to one CO-E32.
LAN cable is not provided.

Adapter for LAN: CO-E32m | DC power supply Benchtop | Matsusada Precision
Adapter for USB: USB-OPT

Total 32 units can be connected to one USB-OPT.
USB cable is not provided.

Adapter for USB: CO-U32m | DC power supply Benchtop | Matsusada Precision
Adapter for RS-232C (9 pin): CO-OPT2-9
Adapter for RS-232C (25 pin): CO-OPT2-25
Adapter for RS-485 (25 pin): CO-OPT4-25

Total 32 units can be connected.

Adapter for RS-232C: CO-MET2-9< | DC power supply Benchtop | Matsusada Precision
Adapter for GPIB: CO-G32

Total 32 units can be connected to one CO-G32.
GPIB cable is not provided.

Adapter for GPIB: CO-G32m | DC power supply Benchtop | Matsusada Precision
For details, refer to CO/USB series datasheet.
(A) Optical fiber cable
Lls/-LIs10 *1

Isolated remote control
Output control signal is isolated from common (=outputΘ) so that floating of control signal is not required when negative output operation or series connection
(isolation voltage from outputΘ is below 250 V)

  • Output control

    [-LIs] CV: External control voltage 0 to 5 Vdc, CC: External control voltage 0 to 5 Vdc

    [-LIs10] CV: External control voltage 0 to 10 Vdc, CC: External control voltage 0 to 10 Vdc

  • Monitor output

    [-LIs] Output voltage monitor: 5 V/Maximum output voltage, Output current monitor: 5 V/Maximum output current

    [-LIs10] Output voltage monitor: 10 V/Maximum output voltage, Output current monitor: 10 V/Maximum output current

  • Other functions

    [-LIs/-LIs10] External output ON/OFF, Status signal output (CC, OUTPUT and Stand-by)

-LLp

10-turn potentiometer with lock (both voltage and current)
Only for models less than 300 V

-LOcp *4

Overcurrent protection (OCP)
Cut off the output at set current value. Local setting only.
Setting range: 5% to 110% of maximum rated current, Local setting: 1-turn volume on front panel
Reset : Manual recover y by OUTPUT switch or External output ON/OFF

-LPfc *4

Power factor correction circuit (Three-phase input of 3.75 kW to 15 kW type only)
Size of the case will be different. Contact nearby sales office for more details for this option.

-LUs1 *1

USB Interface Board

-L(220V)

Input voltage: 220 Vac ± 10%
for 0.75 kW to 1.2 kW models Input current will be about 105% of typical value

-L(230V)

Input voltage: 230 Vac ±10%
for 1.8 kW to 15 kW models
Input current will be about 95% of typical value

-L(240V)

Input voltage: 240 Vac ±10%

for all models [The models that original input voltage is 230 V]
Input current will be about 95% of typical value
[The models that original input voltage is 220 V]
Input current will be about 90% of typical value
-L(400V)

Input voltage: 400 Vac ± 10%
for 7.5 kW to 15 kW models
Size of the case will be different. Contact nearby sales office for more details for this option.

-L(440V)

Input voltage: 440 Vac ± 10%
for 7.5 kW to 15 kW models
Size of the case will be different. Contact nearby sales office for more details for this option.

  1. These options cannot be selected together. Only one of each can be selected. And, when you connect "Load", "RE series" and "Computer", if you prevent the influence on the computer by the noise that occurred with load, please choose -LGob option. With that in mind, we recommends using it combining our adapter (separated item).
  2. This option cannot be chosen simultaneously with -LGob, -LUs1, -LEt, -LGb or -LIs/-LIs10. However, in being required, please contact our sales office. But, this option cannot be chosen simultaneously with -LOcp.
  3. This option cannot be chosen simultaneously with -LCp.
  4. -LPfc and -L(400V) or -L(440V) cannot be chosen simultaneously.

How to Order

When ordering, add Option No. in the following order by alphabet, and number to Model No.
<Example> RE15-250-LGob(Fc5)LpPfc(240V), RE100-100-LCpIs10LpOcp(400V)

Please ask our offices for a Three-phase AC input cable.

Accessories

AC input cable
Standard
0.75 kW to 2.1 kW
single phase input models on available		 CABLE TYPE5 CABLE series | AC input cable | Matsusada Precision CABLE series | AC input cable | Matsusada Precision 250 V / 25 A 2.5 meters
Sold separately
1.8 kW to 3 kW
three-phase input models on available		 CABLE TYPE6 CABLE series | AC input cable | Matsusada Precision CABLE series | AC input cable | Matsusada Precision 250 V / 25 A 2.5 meters
Sold separately
3.75 kW to 15 kW models on available		 CABLE TYPE7 CABLE series | AC input cable | Matsusada Precision CABLE series | AC input cable | Matsusada Precision 250 V / 75 A 10 meters

Select an appropriate AC input cable according to your operating environment and region.
If you use RE series in Europe, please be sure to contact our sales representatives.

Application software for power supplies and electronic loads

PSS2en series

PSS2en is the dedicated software which can actuate various power supplies, electronic loads and digital controller for power supplies manufactured by Matsusada Precision Inc. with simple set up.
It is the perfect for the aging test, the burn-in test and the withstand voltage test for electronic parts, and for the endurance test, intermittent/continuous operation test or various simulation test for electric component of automobile.

For details, refer to PSS2en page.

PSS2en | Application software for power supplies and electronic loads | Matsusada Precision

Dimensions

For details, download the datasheet below.

Download

The account registration is necessary for downloading

In this website, we provide only the latest version of information including instruction manuals as of our products. Therefore, the newest versions of manuals on the website might be not same as the ones of products you purchased in the past.

Please click here if you are not registered yet to our site.

Membership Registration (Free)

Please click here if you are already registered to our site.

Log in

Information on related articles in Technical Knowledge

Similar products

Products to be used in combination

DC Power Supplies

Search for related to DC Power Supplies

Category
