HIGH POWER & LOW NOISE
HIGH VOLTAGE POWER SUPPLY
- Max Voltage: 0.3kV to 30kV
- Max Current: 4.17mA to 833mA
- Max Power: 125W, 250W
- Designed for best reliability and perfect protection
This embedded module delivers high power, up to 250 W.
The RC series is a high-performance, high-voltage power supply module capable of delivering up to 250 W with low ripple. Despite its high power output, the RC series features a remarkably compact design, contributing to equipment miniaturization. The series is suitable for applications such as capacitor charging and discharging, electron beam generation, and withstand voltage testing, taking advantage of its high power, high voltage, and low noise.
FEATURES AND BENEFITS
- High power up to 250 W on embedded module
- Achieves low noise and high stability despite being a high-power module
- Output voltage control with external potentiometer/external voltage
- Comprehensive protection with a highly reliable design
APPLICATIONS
- Automatic Test Equipment (ATE)
- Capacitor charging
- Electron beam
- High voltage test (Dielectric Breakdown Testing, Hipot testing, etc.)
Models
| Model | Output | Input Current [A] | Ripple [Vp-p] | ||
|---|---|---|---|---|---|
| Voltage [kV] | Current [mA] | Power [W] | |||
| RC125-0.3P | 0.3 kV | 417 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC250-0.3P | 0.3 kV | 833 mA | 250 W | 12.4 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC125-0.6P | 0.6 kV | 208 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC250-0.6P | 0.6 kV | 417 mA | 250 W | 12.4 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC125-1P | 1 kV | 125 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC250-1P | 1 kV | 250 mA | 250 W | 12.4 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC125-1.5P | 1.5 kV | 83.3 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC250-1.5P | 1.5 kV | 167 mA | 250 W | 12.4 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC125-2P | 2 kV | 62.5 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC250-2P | 2 kV | 125 mA | 250 W | 12.4 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC125-3P | 3 kV | 41.7 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC250-3P | 3 kV | 83.33 mA | 250 W | 12.4 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC125-6P | 6 kV | 20.8 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC250-6P | 6 kV | 41.7 mA | 250 W | 12.4 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC125-10P | 10 kV | 12.5 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.05 µF) |
| RC125-15P | 15 kV | 8.33 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.05 µF) |
| RC125-20P | 20 kV | 6.25 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.01 µF) |
| RC125-25P | 25 kV | 5 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.01 µF) |
| RC125-30P | 30 kV | 4.17 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.01 µF) |
| Model | Output | Input Current [A] | Ripple [Vp-p] | ||
|---|---|---|---|---|---|
| Voltage [kV] | Current [mA] | Power [W] | |||
| RC125-0.3N | -0.3 kV | 417 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC250-0.3N | -0.3 kV | 833 mA | 250 W | 12.4 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC125-0.6N | -0.6 kV | 208 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC250-0.6N | -0.6 kV | 417 mA | 250 W | 12.4 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC125-1N | -1 kV | 125 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC250-1N | -1 kV | 250 mA | 250 W | 12.4 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC125-1.5N | -1.5 kV | 83.3 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC250-1.5N | -1.5 kV | 167 mA | 250 W | 12.4 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC125-2N | -2 kV | 62.5 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC250-2N | -2 kV | 125 mA | 250 W | 12.4 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC125-3N | -3 kV | 41.7 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC250-3N | -3 kV | 83.33 mA | 250 W | 12.4 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC125-6N | -6 kV | 20.8 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC250-6N | -6 kV | 41.7 mA | 250 W | 12.4 A | < 1.0 Vp-p (C load ≥ 0.5 µF) |
| RC125-10N | -10 kV | 12.5 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.05 µF) |
| RC125-15N | -15 kV | 8.33 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.05 µF) |
| RC125-20N | -20 kV | 6.25 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.01 µF) |
| RC125-25N | -25 kV | 5 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.01 µF) |
| RC125-30N | -30 kV | 4.17 mA | 125 W | 6.2 A | < 1.0 Vp-p (C load ≥ 0.01 µF) |
Specifications
- Input voltage
- 24 Vdc
- Output voltage control
- External 5 kΩ potentiometer or external control voltage (Vcon-in) 0 to 5 Vdc
Diagram
Connection diagram
Dimensions
125W models: 101 x 100 x 39mm (3.98" x 3.94" x 1.54")
250W models: 203 x 100 x 39mm (7.99" x 3.94" x 1.54")
For details, download the datasheet below.
