MINI-FOCUS X-RAY MODULE

  • Twin box
  • X-ray tube voltage: 5kV to 80kV
  • X-ray power: 15W to 50W

MINI-FOCUS X-RAY MODULE

XWF series is a 2-unit type X-ray module of high stability power supply and X-ray tube integrated. The unit generates stable mini-focus X-ray output. High power X-ray output of a maximum of 50 watts enables obtaining a high contrast image. The best suitable unit for positioning, circuit pattern check, and imagining.

FEATURES AND BENEFITS

  • 50 µm X-ray tube type
  • Unique control method suppress noise from connection wire
  • Stable X-ray generation
  • Simple and easy operation with controller unit
  • Continuous operation

APPLICATIONS

Models

Model Anode voltage Beam current Max Power Focal spot size Radiation angle Window material Operation X-ray leakage (at 5cm)
XWF15-50 5 kV to 50 kV 0.3 mA 15 W 50 µm 22° Be Continuous 5 µSv/hr
XWF50-50 5 kV to 50 kV 1 mA 50 W 85 µm 25° Be Continuous 5 µSv/hr
XWF24-80 5 kV to 80 kV 0.3 mA 24 W 50 µm 32° Be Continuous 5 µSv/hr
XWF50-80 5 kV to 80 kV 0.625 mA 50 W 85 µm 20° Be Continuous 5 µSv/hr

For details, download the datasheet below.

Functions

  • X-ray remote ON/OFF
  • Anode voltage and Beam current monitor
  • Reference voltage output for control

Specifications

For details, download the datasheet below.

Accessory

CN-XWF(3)

3 meters connection cable

Dimensions

For details, download the datasheet below.
